Speakers - HD6 Audio Engine

$699.00

Description

HD6 HOME MUSIC SYSTEM W/ BLUETOOTH APTX-HD

Our flagship HD6 premium powered speakers are a complete home music system with bold stereo sound that fills any room. Wired or wireless connections, including digital optical from your TV, aptX-HD Bluetooth from your phone, or good old analog from that vintage turntable or 80’s Sony tape deck.

    • Type
      Powered Bluetooth aptX HD speaker system

      Amplifier Type
      Class AB

      Power Output
      150 W peak power total (50 W RMS / 75 W peak per channel), AES

      Drivers
      5.5″ aramid fiber woofers

      1″ silk dome tweeters

      Inputs
      3.5 mm stereo mini-jack, RCA L/R, digital optical (SPDIF,) Bluetooth aptX

      Outputs
      RCA variable line-out

      Input Voltages
      115/240 V, 50/60 Hz manually switchable

      SNR
      >95 dB (typical A-weighted)

      THD+N
      <0.05% at all power settingsCrosstalk
      <50 dBFrequency Response
      50 Hz-22 kHz ±1.5 dB

      Analog Input Impedence
      48K ohms unbalanced (mini-jack and RCA inputs)

      Protection
      Output current limiting, thermal over-temperature, power on/off transient protection, replaceable external main fuse

      Power Consumption
      Idle: 10 W
      Mute: 6 W
      Sleep: 4 W


    • BLUETOOTH SPECIFICATIONS


      Internal D/A Converter
      AKM AK4396

      Input Bit Depth
      24 bit (padded)

      Bluetooth Receiver Type
      Bluetooth 5.0

      Supported Codecs
      aptX HD, aptX, AAC, SBC

      Wireless Operation Range
      Up to 100 ft (30 m) typical

      Input Data Rate
      Determined by Bluetooth

      Wireless Latency
      ~30 milliseconds (ms)


    • OPTICAL SPECIFICATIONS


      Internal D/A converter
      AKM AK4396

      Input Bit Depth
      up to 24 bit native

      Input Data Rate
      up to 192 kHz native


    • WEIGHTS AND MEASURES


      Dimensions (HWD)
      Left speaker (active)
      Dimensions: 11.75″ (30 cm) x 7.25″ (18.5 cm) x 10″ (25 cm)
      Right speaker (passive)
      Dimensions: 11.75″ (30 cm) x 7.25″ (18.5 cm) x 10″ (25 cm)

      Weight
      Left (active) – 17.5 lb (8 kg)
      Right (passive) – 12.5 lb (5.5 kg)

      Total Shipping Weight
      33.5 lb (15 kg)

      Shipping Box Dimensions (LWH)
      20″ (51 cm) x 15″ (38 cm) x 17″ (43 cm)


    • ENVIRONMENTAL REQUIREMENTS


      Operating temperature: 32 degrees F to 95 degrees F
      Non-operating temperature: -4 degrees F to 113 degrees F
      Relative humidity: 5% to 95% non-condensing


    • MATERIALS AND CONSTRUCTION


      0.7″ (18 mm) thick MDF cabinets with real wood veneer
      1″ (26 mm) silk dome tweeters with neodymium magnets
      5.5″ (140 mm) aramid fiber woofers with advanced voice coils


  • CABINETS


    To minimize unwanted resonances and distortion, Audioengine cabinets have thick high-resin MDF walls with extensive internal bracing. Heavy internal sound-damping material is used to reduce unwanted sound reflections inside the cabinet. All cabinet edges are rounded which look great and reduce high-frequency diffraction effects on the front baffles. The HD6 cabinet contains tuned, rear-port slots.
SKU: 033210  |  Barcode: 819955270167
